Suction box incl. 12.5 kW side channel blower, filter pre-separator and BigBag disposal
The container suction unit includes:
- Intake box is a closed housing box with ventilation slots
- 12.5 KW side channel blower and silencer
- Frequency inverter for infinitely variable regulation of the volume flow
- PLC on board for filter control
- Remote ON/OFF
Technical data of the side channel blower:
- Power = 12.5 kW / 400 Volt
- Air volume max. = 1,100 m³/h
- Vacuum 360 / 420 max.
The filter pre-separator includes:
- 3x 5.0m² dust class “M” cartridge filter
- With automatic compressed air cleaning for better separation performance and longer filter service life
- Cyclone pre-separator for large quantities of dust
- Mobile BigBag frame with height adjustment
