EP 2830/ 2855/ 2875 Industrial extraction system
- Very strong suction power, suitable for pipe systems, with various openings for connection
- Frequency inverter for automatic volume flow control, fully equipped with safety features
- Remote on/off possible with practical handheld
- Monitoring of dirt container fill level, including convenient lowering for disposal
Upgrades
Exhaust air opening with flare connection Ø 250 mm Standard: top - optionally left, right or rear
Exhaust air opening with flare connection Ø 250 mm Standard: top - optionally left, right or rear
Chamber with medium-pressure turbine
Upgrade: Position additional filter chamber for H-filter (except for EP 2875) and/or activated carbon module (only for EP 2830) - device is approx. 50 cm higher per chamber
Intake opening with non-return flap Ø 250 mm Standard: right - optionally left or rear
Standard: 60 L dirt container with swivel castors - upgrade to 100L possible
Exhaust air opening with flare connection Ø 250 mm Standard: top - optionally left, right or rear
Exhaust air opening with flare connection Ø 250 mm Standard: top - optionally left, right or rear
Main switch
Compressed air connection for pneumatic filter cleaning
Intake opening with non-return flap Ø 250 mm Standard: right - optionally left or rear
Intake opening with non-return flap Ø 250 mm Standard: right - optionally left or rear
Intake opening with non-return flap Ø 250 mm Standard: right - optionally left or rear
*) Operating data including standard filter equipment in factory condition without further options such as spark trap, duct or H-upgrade, etc. The operating point varies due to power setting and pipe design (Ø, length) as well as detection at the intake point.
**) Based on the standard version and varies depending on the device equipment
Very powerful stationary extraction system with high air volume for capturing and filtering dry and hazardous dusts.
Ideal for extracting free-flowing, dry dust and fumes when Welding, grinding, polishing, cutting metals or plastics or at transfer stations.
High quality standards – maintenance-free medium-pressure turbine IE3 suitable for 3-shift operation. Ideal for extracting large volumes of air to capture airborne dust – e.g. from laser cutting. Convenient lowering of the dirt container for easy disposal of the suction material
Modern cartridge filter system: Resistant polyester filters with large filter surface in dust class M.
Dust class H available on request.
On the control side including monitoring and display of filter status.
Automatic time-controlled cleaning of the cartridge filters using compressed air (external compressed air connection required). Integrated impact separator for pre-separation of coarse suction material.
Upgrade EX protection: Device completely earthed through as a preventive protective measure for safe use according to ATEX in Zone 22.
Optional additional protective measures, e.g. relief valve or rupture disk available on request.
Upgrade ESD version
- Completely earthed
- ESD powder coating
- Feet/castors ESD
Energy-efficient control system that can be adapted to customer processes:
Suction flow control (PID): The air volume requirement is determined by sensors in the system and the frequency inverter automatically regulates to the appropriate negative pressure (mbar display) or
Speed control: The output of the system is set to a fixed speed (Hz. display).
